Stamp-Pico DIY Kit

SKU:K051-B

Description

The Stamp-Pico DIY Kit is a development kit for the Stamp-Pico minimal core board. The kit includes the Stamp-Pico, along with pin headers, pin sockets, HY2.0-4P female connectors, and an ESP32 Downloader. The pin order of the ESP32 Downloader matches the serial download pin order on the Stamp-Pico, allowing for direct insertion into the solder pad holes for program burning. The Stamp-Pico is a cost-effective Wi-Fi minimal core board. The module features the ESP32 main control chip, which includes two low-power Xtensa® 32-bit LX6 microprocessors with a clock speed of up to 240MHz. The Stamp-Pico is compact, high-performance, and can be easily embedded into your application circuits to build IoT applications.

Tutorial

This tutorial will guide you on how to control the Stamp-Pico using the UIFlow graphical programming platform.
This tutorial will guide you on how to program and control the Stamp-Pico using the Arduino IDE.

Features

  • ESP32-PICO-D4 (2.4GHz Wi-Fi)
  • Multiple IO ports for various application forms (SMT, DIP, flying leads)
  • Integrated programmable RGB LED and button
  • ESP32 minimal system board
  • High-temperature plastic armor for better protection of the 3D antenna and components
  • Includes 5V->3.3V DC/DC circuit, GPIOx12, programmable RGB LED x1, button x1
  • Professionally tuned RF circuit for stable and reliable wireless communication quality.
  • Development Platform
    • UiFlow1
    • UiFlow2
    • Arduino IDE
    • ESP-IDF
    • PlatformIO

Includes

  • 1 x Stamp-Pico
  • 1 x 2.54-9P pin header
  • 1 x 2.54-9P pin socket
  • 1 x 2.54-6P pin header
  • 1 x 2.54-6P pin socket
  • 1 x High-temperature resistant sticker
  • 1 x HY2.0-4P female connector (90°)
  • 1 x L-shaped hex key 1.5mm (for M2 screws)
  • 1 x ESP32 Downloader

Applications

  • Smart home
  • Wearable devices
  • Medical devices

Specifications

Main Control Resources Parameters
ESP32-PICO-D4 240MHz dual core, 600 DMIPS, 520KB SRAM, Wi-Fi Package: LGA48 (7*7mm)
Flash 4MB
Input Voltage 5V @ 500mA
Power Consumption Normal standby: 5V@29mA, WIFI STA mode: 5V@60mA, Classic Bluetooth mode data transmission: 5V@84mA, DeepSleep mode: 5V@0.35mA
Wireless Range AP mode: 16m, BLE mode: 110m, Classic Bluetooth mode: 90m
Human-Machine Interface Programmable physical button x 1, programmable RGB LED (SK6812) x 1
Antenna Type 2.4G 3D antenna
Wi-Fi 802.11 b/g/n (802.11n up to 150 Mbps), Frequency range: 2.4 GHz ~ 2.5 GHz
Module Resource Interface ADC, DAC, touch sensor, SD/SDIO/MMC host controller, SPI, SDIO/SPI slave controller, EMAC, motor PWM, LED PWM, UART, I2C, I2S, infrared remote controller, GPIO, pulse counter
IO Interface x12 G0, G1, G3, G26, G36, G18, G19, G21, G22, G25, G32, G33
IO Interface Spacing 2.54mm
Operating Temperature 0 ~ 60°C
Screw Specifications M2 x 4 countersunk hex screws
Product Size 24.0 x 18.0 x 4.6mm
Product Weight 2.6g
Packaging Size 138.0 x 93.0 x 5.6mm
Gross Weight 9.6g

Learn

Program Download

  • The Stamp-Pico uses a minimal circuit design and does not include a program download circuit. Users can use a USB-TTL burner for program downloading, as shown in the wiring diagram below.

Shell Supports Reflow Soldering Temperature Curve

Schematics

PinMap

SK6812, Button

ESP32 G27 G39
SK6812 DI /
Button / SW

Model Size

PCB

Datasheets

Softwares

Arduino

UiFlow1

UiFlow2

USB Driver

Before burning, you need to connect a USB-TTL burner board to the Stamp-Pico and connect it according to the board's silk screen. Install the corresponding burner board driver on your PC.

The most convenient way is to purchase the Stamp-Pico kit with a downloader . The downloader's pin order matches the STAMP-PICO, allowing direct plug-in for burning without wiring. Currently, M5 provides two versions of downloaders with different driver chips: CP210X (for CP2104 version) / CH9102 (for CH9102 version) driver packages. After extracting the package, select the installation package corresponding to your operating system's bit version. (If you are unsure which USB chip your device uses, you can install both drivers.)
Driver Name Applicable Driver Chip Download Link
CP210x_VCP_Windows CP2104 Download
CP210x_VCP_MacOS CP2104 Download
CP210x_VCP_Linux CP2104 Download
CH9102_VCP_SER_Windows CH9102 Download
CH9102_VCP_SER_MacOS v1.7 CH9102 Download
MacOS Port Selection
In MacOS, two optional ports may appear. Please select the port named wchmodem for use.
