Guide Rail
Description
Guide Rail is an expansion base with a rail structure designed for the M5Base series. It features a spring-loaded rail clip mechanism at the bottom and provides multiple M3 screw holes, offering flexible and versatile mounting options.
Features
- Spring-loaded rail fixation
- Screw fixation holes
Includes
- 1 x Guide Rail mounting base
Specifications
| Specification | Parameter |
|---|---|
| Net Weight | 10.0g |
| Gross Weight | 13.0g |
| Product Size | 100 x 7mm |
| Package Size | 95 x 69 x 8mm |
