Base M5GO Charger

SKU:A016

Description

Base M5GO Charger is a magnetic charging base designed for devices equipped with the Base M5GO Bottom series (such as M5GO, Fire, etc.). When connected to a power supply, the base charges the Base M5GO Bottom conveniently via Pogo Pins. The base features LEGO-compatible holes and screw holes, making it easy to mount on various surfaces.

Includes

  • 1 x Base M5GO Charger
  • 1 x USB Type-C Cable (1m)

Specifications

Specification Parameter
Product Weight 23.6g
Gross Weight 70.0g
Product Size 54.5 x 54.5 x 11.2mm
Package Size 95.0 x 66.0 x 26.0mm

Learn

When charging, the charging indicator light on the device base will keep flashing. Once the indicator light stays on, it means charging is complete.

Model Size

PinMap

M5-Bus

PIN LEFT RIGHT PIN
GND 1 2 NC
GND 3 4 NC
GND 5 6 NC
NC 7 8 NC
NC 9 10 NC
NC 11 12 3V3
NC 13 14 NC
NC 15 16 NC
POGO_PIN_SDA 17 18 POGO_PIN_SCL
NC 19 20 NC
NC 21 22 NC
NC 23 24 NC
NC 25 26 NC
NC 27 28 5V
NC 29 30 BAT
