Unit PoE CAM-W v1.1
SKU:U121-B-V11
Description
Unit PoE CAM-W v1.1 is a programmable PoE camera based on the “ESP32+W5500” solution, equipped with a built-in 3MP OV3660 image sensor featuring a 66.5° field of view, and integrating PoE (Power over Ethernet, max power consumption 6W) and Wi-Fi functions. It features 16MB Flash and 8MB PSRAM, with a reserved program download interface. This camera is equipped with abundant interfaces and functional modules, including a button (G37), LED indicator (G0), Grove interface (EXT_PORT), and expansion IO pins, along with a camera mounting clip and LEGO-compatible clamp. Suitable for image monitoring, remote acquisition, smart home, industrial automation, and other fields.
Tutorial
This tutorial will introduce you to how to program and control the Unit PoE CAM-W v1.1 device using Arduino IDE
This tutorial will introduce the M5PoECAM-W V1.1 device tutorial & quick start
Features
- Built-in ESP32-D0WDQ6-V3 (supports 2.4G Wi-Fi)
- 3MP camera OV3660
- Ethernet chip W5500
- LAN speed up to 10M or 100M (depending on the provided connection)
- PoE IEEE802.3 AF standard (max power 6W)
- Built-in LED indicator
- Standard RJ45 Ethernet interface
- Compatible with standard LEGO interface and comes with camera mount
- Development Platform: Arduino, ESP-IDF
Includes
- 1 x Unit PoE CAM-W v1.1
- 1 x Camera Mounting Clip
- 1 x LEGO-Compatible Clip
Applications
- Warehouse monitoring
- Timed photography
- Machine vision
- Smart home monitoring
Specifications
| Specification | Parameter |
|---|---|
| SoC | ESP32-D0WDQ6-V3 |
| Camera Module | OV3660@3Megapixel |
| DFOV | 66.5° |
| Ethernet Chip | W5500 |
| Flash | 16MB |
| PSRAM | 8MB |
| Wi-Fi | 802.11 b/g/n |
| Pixel Size | 1.75µm x 1.75µm |
| Output Format | RAW RGB565/555/444 YUV422/420 YCbCr422 JPEG |
| Auto Image Control | Auto Exposure Control (AEC) Auto Gain Control (AGC) Auto White Balance (AWB) Auto Band Filter (ABF) and Auto Black Level Calibration (ABLC) |
| Supported TCP/IP | TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE |
| Ethernet Interface | RJ45 |
| PoE | PoE IEEE802.3 AF standard (max power 6W) |
| Product Size | 64.0 x 24.0 x 18.0mm |
| Product Weight | 20.6g |
| Package Size | 80.0 x 38.0 x 33.0mm |
| Gross Weight | 44.6g |
Learn
Program download diagram
Schematics
1/1
PinMap
- Grove interface & Button & LED indicator
| ESP32-D0WDQ6-V3 | G33 | G25 | 5V | GND | G37 | G0 |
|---|---|---|---|---|---|---|
| Grove | SCL | SDA | VCC | GND | ||
| Button | Button | |||||
| LED (Blue) | LED |
- Expansion pins (download pins)
| ESP32-D0WDQ6-V3 | CHIP_UP | G0 | GND | VCC | G1 | G3 |
|---|---|---|---|---|---|---|
| Expansion pin | EN | G0 | G | 3.3V | G1 | G3 |
Model Size
Datasheets
Softwares
Arduino
- Unit PoE CAM-W v1.1 Arduino Quick Start
- Unit PoE CAM-W v1.1 Arduino Library
- Unit PoE CAM-W v1.1 Button Example
- Unit PoE CAM-W v1.1 Capture Example
- Unit PoE CAM-W v1.1 HTTP POST Example
- Unit PoE CAM-W v1.1 LED Control Example
- Unit PoE CAM-W v1.1 RTSP Example
- Unit PoE CAM-W v1.1 Web CAM Example
EasyLoader
| Easyloader | Download | Note |
|---|---|---|
| Unit PoE CAM-W v1.1 Firmware Easyloader | download | / |
Video
- Unit PoE CAM-W V1.1 HTTP STREAM
