ENV III HAT is a multifunctional environmental sensor adapted to the M5StickC series. It integrates SHT30 and QMP6988 internally to detect temperature, humidity, and atmospheric pressure data. SHT30 (0x44) is a high-precision, low-power digital temperature sensor. Humidity sensor. QMP6988 (0x56) is an absolute air pressure sensor specially designed for mobile applications with high accuracy. For projects that require rapid collection and detection of environmental data, ENV-III HAT is a balanced performance Good choice with cost performance.
|Maximum temperature measurement range||-40 ~ 120 ℃|
|Highest measurement accuracy||0 ~ 60 ℃/±0.2℃|
|Humidity measurement range/error||10 ~ 90 %RH / ±2%|
|Maximum measured value of air pressure/resolution/error||300 ~ 1100hPa / 0.06Pa / ±3.9Pa|
|Communication protocol||I2C: SHT30(0x44), QMP6988(0x56)|
|Working temperature||32°F to 104°F (0°C to 40°C )|
|Case Material||Plastic ( PC )|
|ENV III HAT||SCL||SDA||3.3V||GND|
Execute the following statement in Setup() of the Arduino program
When M5Core2 is stacked with other M5 modules, you need to remove the battery base of Core2, which does not support module stacking.
Reason and solution: The power supply current of the port is insufficient, which can cause the device to not enter the download mode normally. You can try to connect a capacitor (>0.1uF) between the RST pin and the GND pin, or when uploading the program, set the G0 Short-circuit to GND, so that G0 can be set to a low level state normally
Add the header file #include <driver/adc.h> and the function adc_power_acquire(); in the Arduino program
The battery life of the controller is affected by various factors such as battery capacity, operating status, and load, so there is no fixed value. Reducing the load and adopting a sleep strategy can effectively increase the battery life.
Support multiple stacks, the total capacity of the batteries in parallel increases, and the voltage remains unchanged. However, since the discharge of each battery is not balanced during use, there is a voltage difference between the batteries, which may cause the battery to charge backwards. .(will lose part of the battery capacity)
ESP32 module currently does not support WiFi in 5G band, only 2.4G.
Confirm whether the TX/RX pin on the TTL side of the pin is correct, try to add two 120Ω terminal resistors at the beginning and end of the device line to reduce signal reflection interference
