Unit Watering
SKU:U101
Description
Watering is a capacitive soil moisture detection and adjustment unit. The product integrates water pump and measuring plates for soil moisture detection and pump water control. It can be used for intelligent plant breeding scenarios and can easily achieve humidity detection and Irrigation control. The measurement electrode plate uses the capacitive design, which can effectively avoid the corrosion problem of the electrode plate in actual use compared with the resistive electrode plate.
Product Features
- Capacitive measuring plate (corrosion resistant)
- Integrated 5W power water pump
- LEGO compatible holes
Includes
- 1x Watering Unit
- 2x suction pipe
- 1x HY2.0-4P cable
Application
- Plant cultivation
- Soil moisture detection
- Smart irrigation
Specification
| Resources | Parameter |
|---|---|
| Pump power | 5W |
| Net Weight | 78g |
| Gross Weight | 103g |
| Product Size | 192.5*24*33mm |
| Package Size | 200*35*45mm |
EasyLoader
Windows
MacOS
PinMap
| M5Core(PORT B) | GPIO26 | GPIO36 | 5V | GND |
|---|---|---|---|---|
| Watering Unit | PUMP | INPUT | 5V | GND |
Schematic
Module Size
Example
Arduino
UIFlow
How to use Blockly watering on the UIFlow 1.0 graphical programming platform and related API instructions
How to use Unit watering and related API instructions in the UIFlow2.0
Video
- Watering introduce
- Watering Unit UIFlow 2.0 Use
